Dumbbell Sample Cutting Dies
<p class="stock in-stock"></p>
Dumbbell sample cutting dies for cables are used to create samples for tensile and elongation at break tests as well as for hotset and aging-related tests of material.
Dumbbell sample cutting dies is used for making test piece by punch before performing another test like a tensile, tear, or peeling on a universal peeling machine. With the help of this machine we can make an accurate test piece and save lots of time
Two types of dumbbell dies are available in stock:
| Die for Tensile Test 75 mm (Tungsten Steel grade) |
| Die for Tensile Test 50 mm (Tungsten Steel grade) |
We have three types of cutter:
- Chromium Steel
- Chromium steel with Spring Mechanism
- Wood-Based Double wood mounted with steel plate
Every Tech Trivial product gives you exactly what you need: accurate measurements, consistent, reliable performance, best possible safety, and best possible warranty available
Standard Accordance:
It is made according to ASTM D 412, ASTM D 638, EN 455, ISO 37, ISO 34, ASTM D 624.
Features:
Accuracy: ± 0.05 mm
Model No.: D1014
Applicable materials are rubber, polymer, paper, foam and sponge, fiber, foil, textile, and leather.
Optional accessories are Cutting Board – PP material, Custom made slot adaptor, Pneumatic die cut machine, cable sample cutting die
Dumbbell sample cutting dies
You can also check out our more Machinery Products.
